4K 60Hz (4:4:4) Input, 1080P 60Hz Output H.264 H.265 HDMI IPTV Encoder with Audio Embedding and PoE

The J-Tech Digital JTECH-ENCH4AP HDMI encoder is a versatile solution for IPTV streaming and live broadcasting. It supports H.264, H.265, and MJPEG compression to deliver efficient bandwidth usage and high-quality video, along with compatibility for RTSP, RTP, RTMP, RTMPS, HTTP, UDP, TS, and ONVIF protocols for flexible network integration. The unit features 4K@60Hz (4:4:4) HDMI Input and 1080P@60Hz Output with 3.5mm analog audio embedding for synchronized audio and video, making it ideal for live events, churches, and professional AV setups. Stream up to four platforms simultaneously using one main stream and three substreams. Customizable OSD, logo overlay, and a no signal image allow for a fully branded and professional viewing experience. With Power over Ethernet support, installation is simple and efficient using a single cable for both power and data, requiring a PoE network switch.

✅ Supports H.265, H.264, and MJPEG video encoding

✅ Supports up to 4K@60Hz (4:4:4) Input and 1080P@60Hz Output

✅ HDMI input with external audio input support

✅ Compatible with UDP, HTTP, RTSP, RTMP, SRT, HLS, FLV, and ONVIF

✅ Supports MPEG1 Audio Layer 2 encoding

✅ Adjustable CBR/VBR bitrate from 32Kbps to 32Mbps

✅ 100M Ethernet interface with full duplex support

✅ Image parameter adjustment for video optimization

✅ Remote management via web GUI over LAN or WAN

✅ Custom resolution configuration support

✅ Power over Ethernet support for single cable setup
